GU-3900B series “General Function” Software Specification
4.7.3.10
Macro setting commands
Command Name
Hex Code
Operation
Page
RAM Macro define / delete
1Fh,3Ah,pL,pH,
d1...dk
Define or delete RAM Macro or RAM Program Macro.
pL:
RAM Macro data length, lower byte
pH:
RAM Macro data length, upper byte
d1...dk:
RAM Macro data
p57
FROM Macro define / delete
(Only valid in User setup
mode)
1Fh,28h,65h,12h,
a,pL,pH,t1,t2,
d(1)...d(p)
Define or delete FROM Macro or FROM Program Macro.
a:
FROM Macro definition number
pL:
FROM Macro data length, lower byte
pH:
FROM Macro data length, upper byte
t1:
Display time interval
t2:
Idle time for Macro repetition
d(1)...d(P):
FROM Macro data
p57
Macro execution
1Fh,5Eh,a,t1,t2
Continuously execute Macro.
a:
Macro processing definition number
a=00h:
RAM Macro
a=01h–04h:
FROM Macro 1–4
a=80h:
RAM Program Macro
a=81h–84h:
FROM Program Macro 1–4
t1:
Display time interval
t2:
Idle time for Macro repetition
p58
Macro end condition
1Fh,28h,69h,20h,
a,b,c
Default: a=00h,
b=00h, c=00h or
Memory SW
setting.
Macro end condition set.
(Not applicable for Program Macro)
a: Macro end code Enable/Disable
b: Macro end code
c: Macro end Clear Screen setting
p59
4.7.3.11
Other setting commands
Command Name
Hex Code
Operation
Page
Memory SW setting
(Only valid in User setup
mode)
1Fh,28h,65h,03h,
a,b
1Fh,28h,65h,03h,
a,b,c[1],d[1]
[...c[b],d[b]]
Set Memory SW.
Single setting:
a: Memory SW number
b: Setting value
Multiple setting (a=FFh):
b: Number of settings
c: Memory SW number
d: Setting value
p59
Memory SW data send
1Fh,28h,65h,04h,a
1Fh,28h,65h,04h,
a,b,c[1] [...c[b]]
Send the contents of Memory SW data.
Single read:
a: Memory SW number
Multiple read: (a=FFh)
b: No. of reads
c: Memory SW number
p60
General-purpose memory
store
1Fh,28h,65h,18h,
sL,sH,sE,m1,
a1L,a1H,a1E,
d[1]...d[s]
Store the supplied data into general-purpose memory.
sL:
Data size, lower byte
sH:
Data size, upper byte
sE:
Data size, extension byte
m1:
Memory select
a1L:
Memory address, lower byte
a1H:
Memory address, upper byte
a1E:
Memory address, extension byte
d:
Data to store
p60
General-purpose memory
transfer
1Fh,28h,65h,19h,
sL,sH,sE,m1,
a1L,a1H,a1E,m2,
a2L,a2H,a2E
Transfer data between general-purpose memory areas.
sL:
Transfer size, lower byte
sH:
Transfer size, upper byte
sE:
Transfer size, extension byte
m1:
Destination memory select
a1L:
Destination address, lower byte
a1H:
Destination address, upper byte
a1E:
Destination address, extension byte
m2:
Source memory select
a2L:
Source address, lower byte
a2H:
Source address, upper byte
a2E:
Source address, extension byte
p61
